Nova 4

  • Suitable for wood shelf panels from 25 mm onwards
  • With wall bolt and two suspension for maximum stability
  • Height and tilting adjustable
  • Bolts length 100 (drilling depth 115 mm) or 165 (drilling depth 185 mm)
  • Mounting plate ready assembled, bolts bulk
  • Loading group L 75 (DIN 68874)
Type Art. No.
Bolt 100 mm 24.500.40
Bolt 165 mm 24.500.50
Universal dowel ø 8 x 50 mm 24.200.24
Screw Torx ø 5,5 x 60 24.200.20
Full set, consisting of 2 supports, 4 dowels and 4 screws
with bolt 100 mm 24.500.40-V1
with bolt 165 mm 24.500.50-V1
blueprint
blueprint
blueprint
